| Laser Source Built-in |
Built-In, Diode Pumped Nd:YAG |
| Wavelength |
1064 nm |
| Laser Source Output |
1 W @ 5 kHz |
| Peak Power |
Up to 30 kW |
| Q-switch pulse width |
~8 ns @ 5 kHz |
100mm F-Theta Lens:
Beam Spot Diameter
Max Marking Area |
50 - 60 µm
2.5 x 2.5”
65 x 65 mm |
160mm F-Theta Lens:
Beam Spot Diameter
Max Marking Area |
70 - 80 µm
4.1 x 4.1”
105 x 105 mm |
| Lenses available(back focal length) |
100 & 160 mm |
| Cooling System |
Air-cooled |
| Operational Temp Range |
~50 -104 ˚F ~10 - 40 ˚C |
| Operational Humidity Range |
85% non-condensing |
| Weight |
11 lbs (5 kg) |
| Dimensions** |
11.8 X 5.2 X 6.6"
300 X 131 X 168 mm
(without F-theta lens) |
