HOME 產品介紹 ALLTEC

UV M3000

UV Laser Marking Machine

  • 商品特色

Laser Marking Machine
M3000 with UV laser







新進高端的雷射雕刻視覺系統
Advanced laser workstations with vision inspection for
economic direct part marking and reliable product traceability

  • 商品說明
  • 商品規格
  • 相關推薦
Technical Specifications M3000-B/P-UV with UV laser marking system
Model B: Laser marking workstation with worktable and programmable Z-axis
P: Laser marking workstation with programmable axes (X, Y, Z)
Available laser systems UV: V.0020-uv
Features B: Worktable, Z-axis, electric lift door | P: Axes X, Y, Z, electric lift door
User interfaces Laser marking software FOBA MarkUS™
Axes*** Programmable Z-axis:
  • Travel 350 mm | 13.78 in,
  • Travel speed 25 mm/s | 0.98 in (1.5 m/min | 59 in/min)
Programmable axes X and Y:
  • Travel X-axis 520 mm | 20.47 in
  • Travel Y-axis 150 – 225 mm | 5.90 x 8.86 in
  • Travel speed 100 mm/s | 3.937 in/s (6 m/min | 236.22 in/min) each
Dimensions (W x D x H) 1,200 x 1,688 x (1,899 up to 2,199) mm* | 47.24 x 66.45 x (74.76 up to 86.57) in*
Footprint 2 m² | 3,100 in²
Working chamber 0.2 m³ | 12,204.7 in³
Door opening (W x H) 970 x 450 mm | 38.19 x 17.71 in
Weight** approx. 675 kg | 1,488.12 lbs
Safety class  Laser class 1 (according to IEC 60825-1), IP22
Max. load B: 50 kg | 110.23 lbs
P: 30 kg | 66.14 lbs
Max. workpiece size (W x D x H)  B: 970 x 380 x 450 mm | 38.19 x 14.96 x 17.71 in
P: 970 x 490 x 450 mm | 38.19 x 19.29 x 17.71 in
Supply Depends on workspace and utilized laser system
Electrical requirements 1/N/PE, AC 110/230 V, 50/60 Hz
Power consumption Depends on utilized laser system, < 2 kW
Temperature
Humidity		 15 – 40 °C | 59 – 104 °F
90 % (max. 20 °C | 68 °F), 30 % (max. 40 °C | 104 °F),  non-condensing
Options/ accessories
  • Exhaust systems
  • Vision systems
  • Other axes on request
  • Interfaces for the integration of client processes
  • Laser Power Meter
  • PlugIns (Advanced Operator PlugIn)
  • Footswitch
  • automatic height adjustment

* Height adjustment range, height dimensions without foot ** excl. laser and external components *** Depends on configuration and laser and mounting position
